Jazzy 614

Name: Jazzy 614: Footrest Assembly - Gen. 1
Manufacturer: Pride Mobility

Footrest Assembly - Gen. 1 parts diagram

(Click on image to enlarge)

Applicable to Jazzy 614 units manufactured prior to Serial Number J9836108001M10. Applicable to Jazzy 614HD units manufactured prior to Serial Number J9936108001M10.

Pos.	Part #	Description	Remarks	Price	UOM	Buy
A1	FRMASMB12358	FOOT PLATFORM, ASSY, W/MOUNTING BRACKET, JAZZY614		N/A		Please Call
