Catalyst 5 Ti Replacement Parts in Backrest / Catalyst Half Folding Backrest by Ki Mobility

Loading...

Backrest » Catalyst Half Folding Backrest

Catalyst Half Folding Backrest parts diagram
(Click on image to enlarge)

Pos.Part #DescriptionRemarksPriceBuy
3a, 4, 5, 8 - 10504599Half Folding Backrest Hinge Latch Assembly Left
$76.56
3b, 4, 5, 8 - 10504600Half Folding Backrest Hinge Latch Assembly Right
$76.56
3a, 3b, 4, 5, 8 - 10504601Half Folding Backrest Hinge Latch Assembly Pair
$153.12
4101184M6 x 10 BTN SHCS BLKZC w/Patch
$1.50
5000669M6 x 20.5 Threaded Barrel
$4.64
6100803Tube End Plug 7/8"
$1.50
4, 5, 8 - 10504598Half Folding Backrest Hardware Kit
$34.56
1a, 2, 3a, 4 - 6, 7b, 8 - 10504602Half Folding Back Post Assembly Short Straight w/ Standard Push Handle Left
$116.40
1a, 2, 3b, 4 - 6, 7b, 8 - 10504603Half Folding Back Post Assembly Short Straight w/ Standard Push Handle Right
$116.40
1a, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504604Half Folding Back Post Assembly Short Straight w/ Standard Push Handle Pair
$243.89
1b, 2, 3a, 4 - 6, 7b, 8 - 10504605Half Folding Back Post Assembly Tall Straight w/ Standard Push Handle Left
$116.40
1b, 2, 3b, 4 - 6, 7b, 8 - 10504606Half Folding Back Post Assembly Tall Straight w/ Standard Push Handle Right
$116.40
1b, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504607Half Folding Back Post Assembly Tall Straight w/ Standard Push Handle Pair
$243.89
1c, 2, 3a, 4 - 6, 7b, 8 - 10504608Half Folding Back Post Assembly Short Straight w/ Low Profile Push Handle Left
$116.40
1c, 2, 3b, 4 - 6, 7b, 8 - 10504609Half Folding Back Post Assembly Short Straight w/ Low Profile Push Handle Right
$116.40
1c, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504610Half Folding Back Post Assembly Short Straight w/ Low Profile Push Handle Pair
$243.89
1d, 2, 3a, 4 - 6, 7b, 8 - 10504611Half Folding Back Post Assembly Tall Straight w/ Low Profile Push Handle Left
$116.40
1d, 2, 3b, 4 - 6, 7b, 8 - 10504612Half Folding Back Post Assembly Tall Straight w/ Low Profile Push Handle Right
$116.40
1d, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504613Half Folding Back Post Assembly Tall Straight w/ Low Profile Push Handle Pair
$243.89
1e, 2, 3a, 4 - 6, 7b, 8 - 10504614Half Folding Back Post Assembly Short Straight Left
$109.05
1e, 2, 3b, 4 - 6, 7b, 8 - 10504615Half Folding Back Post Assembly Short Straight Right
$109.05
1e, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504616Half Folding Back Post Assembly Short Straight Pair
$228.49
1f, 2, 3a, 4 - 6, 7b, 8 - 10504617Half Folding Back Post Assembly Tall Straight Left
$109.05
1f, 2, 3b, 4 - 6, 7b, 8 - 10504618Half Folding Back Post Assembly Tall Straight Right
$109.05
1f, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504619Half Folding Back Post Assembly Tall Straight Pair
$228.49
1g, 2, 3a, 4 - 6, 7b, 8 - 10504620Half Folding Back Post Assembly Short 8 Degree Bend with Standard Push Handle Left
$125.01
1g, 2, 3b, 4 - 6, 7b, 8 - 10504621Half Folding Back Post Assembly Short 8 Degree Bend with Standard Push Handle Right
$125.01
1g, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504622Half Folding Back Post Assembly Short 8 Degree Bend with Standard Push Handle Pair
$261.93
1h, 2, 3a, 4 - 6, 7b, 8 - 10504623Half Folding Back Post Assembly Tall 8 Degree Bend with Standard Push Handle Left
$125.01
1h, 2, 3b, 4 - 6, 7b, 8 - 10504624Half Folding Back Post Assembly Tall 8 Degree Bend with Standard Push Handle Right
$125.01
1h, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504625Half Folding Back Post Assembly Tall 8 Degree Bend with Standard Push Handle Pair
$261.93
1i, 2, 3a, 4 - 6, 7b, 8 - 10504626Half Folding Back Post Assembly Short 8 Degree Bend with Low Profile Push Handle Left
$125.01
1i, 2, 3b, 4 - 6, 7b, 8 - 10504627Half Folding Back Post Assembly Short 8 Degree Bend with Low Profile Push Handle Right
$125.01
1i, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504628Half Folding Back Post Assembly Short 8 Degree Bend with Low Profile Push Handle Pair
$261.93
1j, 2, 3a, 4 - 6, 7b, 8 - 10504629Half Folding Back Post Assembly Tall 8 Degree Bend with Low Profile Push Handle Left
$125.01
1j, 2, 3b, 4 - 6, 7b, 8 - 10504630Half Folding Back Post Assembly Tall 8 Degree Bend with Low Profile Push Handle Right
$125.01
1j, 2, 3a, 3b, 4 - 6, 7b, 8 - 10504631Half Folding Back Post Assembly Tall 8 Degree Bend with Low Profile Push Handle Pair
$261.93
